For Bulk requirement, Kindly click on enquiry now button Product Details: Product Description Brand Honeywell Model ML7421B8012-E Temperature Operating limits -10… 50 °C at 5…95%rh Storage limits -40… 70 °C at 5…95%rh Valve temperature Max. 150 °C (220 °C with High Temperature Kit) Safety Protection class III according to EN60730-1 Protection standard IP54 according to EN60529 Flame retardant housing V0 according to UL94, with metal cable gland Wiring Wiring terminals 1.5 mm2 Cable entry M20x1.5 and PG11 (the latter with a knock-out for expansion to M20x1.5) Material Cover ABS-FR Yoke and Base Aluminum die-cast Weight 2.0 kg Supply voltage 24 Vac ( 10%/-15%); 50/60 Hz Power consumption 14 VA (50 Hz) / 16 VA (60 Hz) Stroke 38 mm Run-time at 50 Hz 3.5 min Nominal stem force 1800 N Above specifications mentioned are for quick reference only. Actual technical details has to be obtained from below catalog.
